Acrimo Sound

Specificatii:

Second Hand in stare perfecta

FREQUENCY RESPONSE

Flat: 20Hz-20kHz, +0, -0.5dB
Bandwidth: 0.35Hz-80kHz, +0, -3dB
Input Impedance: 40kΩ Balanced/Unbalanced
Max Level: +22dBu

OUTPUT

Impedance: Balanced +4dBu: Balanced: 200Ω, Unbalanced: 100Ω
Max Level: +21dBu into 600Ω

SIDECHAIN INSERT

Input Impedance: >10kΩ
Output Impedance: ≤2kΩ
Max Level: +21dBu
Distortion +Noise: <0.2% any amount of compression at 1kHz

SYSTEM PERFORMANCE

Intermodulation
Distortion: <0.2% SMPTE
Noise: <-93dBu unweighted
Dynamic Range: >114dB, unweighted
Crosstalk: <-93dB @ 1kHz
Common Mode
Rejection: >40dB (Any Frequency)
Stereo Coupling: True RMS Power Summing™
Threshold
Chracteristics: Selectable OverEasy® or hard knee
Exp/Gate: Program Dependent Threshold
Compressor: -40 to +20dB
Expander/Gate: -60 to + 10 dB
Ratio: Compressor: 1:1 to ∞:1
Expander/Gate 1:1 to 4:1

ATTACK TIME

Compressor: Scalable Program Dependent
Expander/Gate: <100 µsec

RELEASE TIME

Compressor: Scalable Program Dependent
Expander/Gate: Program Depenedent

POWER

Power Consumption: 15watts, 100 VAC 50/60 Hz, 120 VAC 60 Hz, 230 VAC 50/60 Hz

PHYSICAL

Dimensions: (H x W x D) 1.75"x5.75"x19" (4.45cm x14.6cm x 48.5cm)
Weight: Net Weight: 5 lbs. (2.3 kg);
Shipping weight: 7 lbs (3.2 kg)
